Name: Traffic Support Pole

Display Field: CWID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This feature class contains points representing poles, traffic signals, flashers, or other features that support traffic signs. This feature class was developed after a 2019 sign collection project by Halff Associates. It is in a one to many relationship with the StreetSigns table. The origin field is the CW ID and it relates to the Post ID field in the StreetSigns table.The attribute table contains information about the support type, location, # of signs, lifecycle, maintenance, condition and inspection date/inspector.Metadata last updated: 6/2021

Service Item Id: d9d166e022e5417fbe82b9ca2a9b8960

Copyright Text: City of Allen

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2508589.936050266
YMin: 7028320.116317555
XMax: 2547261.2413022816
YMax: 7108692.975784406
Spatial Reference: 102738  (2276)  VCSWkid(115702)  LatestVCSWkid(115702)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SupportType
Field 2: MaintainedBy
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSMSCircle
Color: [78, 78, 78, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 1
Default Label: <all other values>
UniqueValueInfos:
• Value: Pole,Allen
  Label: Pole - COA
  Description: N/A
  Symbol:

• Value: Pole,HOA
  Label: Pole - HOA
  Description: N/A
  Symbol:

• Value: Pole,Private
  Label: Pole - Private
  Description: N/A
  Symbol:

• Value: Pole,TxDOT
  Label: Pole - TxDOT
  Description: N/A
  Symbol:

• Value: Pole,NTTA
  Label: Pole - NTTA
  Description: N/A
  Symbol:

• Value: Pole,Collin County
  Label: Pole - Other
  Description: N/A
  Symbol:

• Value: Pole,<Null>
  Label: Pole - Other
  Description: N/A
  Symbol:

• Value: Pole,ISD
  Label: Pole - Other
  Description: N/A
  Symbol:

• Value: Pole,Other
  Label: Pole - Other
  Description: N/A
  Symbol:

• Value: Pole,Plano
  Label: Pole - Other
  Description: N/A
  Symbol:

• Value: Pole,State
  Label: Pole - Other
  Description: N/A
  Symbol:

• Value: Traffic Signal,<Null>
  Label: Traffic Signal
  Description: N/A
  Symbol:

• Value: Traffic Signal,Allen
  Label: Traffic Signal
  Description: N/A
  Symbol:

• Value: Flasher,<Null>
  Label: Flasher
  Description: N/A
  Symbol:

• Value: Flasher,Allen
  Label: Flasher
  Description: N/A
  Symbol:

• Value: Light Post,<Null>
  Label: Light Post
  Description: N/A
  Symbol:

• Value: Light Post,Allen
  Label: Light Post
  Description: N/A
  Symbol:

• Value: Light Post,Private
  Label: Light Post
  Description: N/A
  Symbol:

• Value: Overhang,<Null>
  Label: Overhang
  Description: N/A
  Symbol:

• Value: Overhang,Allen
  Label: Overhang
  Description: N/A
  Symbol:

• Value: <Null>,<Null>
  Label: Other
  Description: N/A
  Symbol:

• Value: Other,<Null>
  Label: Other
  Description: N/A
  Symbol:

• Value: Other,Allen
  Label: Other
  Description: N/A
  Symbol:

• Value: Other,Private
  Label: Other
  Description: N/A
  Symbol:

• Value: Other,Unknown
  Label: Other
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CWID ( type: esriFieldTypeString, alias: CW ID, length: 20 )
• SupportType ( type: esriFieldTypeString, alias: Support Type, length: 50 , Coded Values: [Pole: Pole] , [Traffic Signal: Traffic Signal] , [Flasher: Flasher] , ...3 more... )
• LocationDesc ( type: esriFieldTypeString, alias: Location Description, length: 200 )
• NumSigns ( type: esriFieldTypeSmallInteger, alias: # of Signs )
• Condition ( type: esriFieldTypeString, alias: Condition, length: 50 , Coded Values: [Excellent: Excellent] , [Good: Good] , [Fair: Fair] , ...2 more... )
• LifecycleStatus ( type: esriFieldTypeString, alias: Lifecycle Status, length: 50 , Coded Values: [Active: Active] , [Future: Future] , [Removed: Removed] , ...3 more... )
• MaintainedBy ( type: esriFieldTypeString, alias: Maintained By, length: 50 , Coded Values: [Allen: Allen] , [Allen PR: Allen Public & Media Relations (PAMRO)] , [Collin County: Collin County] , ...16 more... )
• LastServiceDate ( type: esriFieldTypeDate, alias: Last Service Date, length: 8 )
• InspectedDate ( type: esriFieldTypeDate, alias: Inspected Date, length: 8 )
• InspectedBy ( type: esriFieldTypeString, alias: Inspected By, length: 50 )
• Comments ( type: esriFieldTypeString, alias: Comments, length: 500 )
• URL ( type: esriFieldTypeString, alias: URL, length: 500 )
• created_user ( type: esriFieldTypeString, alias: Creator, length: 50 )
• created_date ( type: esriFieldTypeDate, alias: Creation Date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: Last Editor, length: 50 )
• last_edited_date ( type: esriFieldTypeDate, alias: Last Edited Date, length: 8 )
• DecimalDegreeLat ( type: esriFieldTypeString, alias: Decimal Degree Latitude, length: 50 )
• DecimalDegreeLong ( type: esriFieldTypeString, alias: Decimal Degree Longitude, length: 50 )
• EngineerGrid ( type: esriFieldTypeSmallInteger, alias: Engineering Grid # )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )

Relationships:

• SupportPoleToStreetSigns (0) -- Related To: Traffic Signs (8)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates
