Name: Street Lights

Display Field: TYPE_FIXTURES

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This point-based GIS layer provides comprehensive information about street lighting assets across Allen, TX. Each feature includes attributes such as:Ownership: Identifies the entity responsible for the street light (e.g., City of Allen, Oncor, CoServ, GCEC, HOA).Location Description: Provides descriptive information about the feature's location.Maintenance Responsibility: Indicates who is responsible for maintenance activities.Fixture Type: Specifies the type of light fixture installed.Pole Type: Describes the type of pole supporting the light fixture.Installation Date: Records when the street light was installed.Condition: Assesses the current state (e.g., Excellent, Good, Fair, Poor).The dataset is accessible through the City of Allen's GIS Open Data Hub and is compatible with standard GIS applications for advanced querying and analysis.This feature class contains points representing street lights in Allen Tx. It is maintained by Scotty Stewart (Traffic Signal Foreman) in the Engineering department through the Street Light and Street Sign Field Data Collection web map .Metadata updated: 05/2025

Service Item Id: 58bad2c00ab54fa88edd92044ad16e08

Copyright Text: Allen Tx

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2505549.8231514394
YMin: 7078017.557899833
XMax: 2547243.0932062566
YMax: 7108897.050536588
Spatial Reference: 102738  (2276)  VCSWkid(115702)  LatestVCSWkid(115702)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: OWNERSHIP
Field 2: PROVIDER
Field 3: LAMP_TYPE
Field Delimiter: ,
Default Symbol:
Default Label: Unknown
UniqueValueInfos:
• Value: COA,COSERV,HPS
  Label: COA - COSERV
  Description: N/A
  Symbol:

• Value: COA,COSERV,LEDFixture
  Label: COA - COSERV (LED Fixture)
  Description: N/A
  Symbol:

• Value: COA,COSERV,LEDBulb
  Label: COA - COSERV (LED Bulb)
  Description: N/A
  Symbol:

• Value: COA,GCEC,HPS
  Label: COA - GCEC
  Description: N/A
  Symbol:

• Value: COA,GCEC,LEDBulb
  Label: COA - GCEC (LED Bulb)
  Description: N/A
  Symbol:

• Value: COA,ONCOR,HPS
  Label: COA - ONCOR
  Description: N/A
  Symbol:

• Value: COA,ONCOR,LEDFixture
  Label: COA - ONCOR (LED Fixture)
  Description: N/A
  Symbol:

• Value: COA,ONCOR,LEDBulb
  Label: COA - ONCOR (LED Bulb)
  Description: N/A
  Symbol:

• Value: P_R,ONCOR,HPS
  Label: Parks and Recreation - ONCOR
  Description: N/A
  Symbol:

• Value: AISD,ONCOR,HPS
  Label: AISD - ONCOR
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• Engineering_StreetLightDbase ( type: esriFieldTypeInteger, alias: Engineering ID )
• NO_FIXTURES ( type: esriFieldTypeSmallInteger, alias: # of Fixtures , Coded Values: [0: Retire] , [1: Single Fixture] , [2: Double Fixture] , ...2 more... )
• TYPE_FIXTURES ( type: esriFieldTypeString, alias: Type of Fixture, length: 30 , Coded Values: [CH-A: Cobra Head TYPE-A] , [CH-B: Cobra Head TYPE-B] , [CH-C: Cobra Head TYPE-C] , ...7 more... )
• OWNERSHIP ( type: esriFieldTypeString, alias: Street Light Ownership, length: 40 , Coded Values: [AISD: Allen Independent School District] , [COA: City of Allen] , [COSERV: Coserv] , ...19 more... )
• PROVIDER ( type: esriFieldTypeString, alias: Service Provider, length: 40 , Coded Values: [AISD: Allen Independent School District] , [COA: City of Allen] , [COSERV: Coserv] , ...8 more... )
• LAMP_TYPE ( type: esriFieldTypeString, alias: Lamp Type, length: 40 , Coded Values: [MV: Mercury Vapor] , [HPS: High Pressure Sodium] , [MH: Metal Halide] , ...3 more... )
• YR_INSTALLED ( type: esriFieldTypeSmallInteger, alias: Year Light Installed , Range: [1800, 2500] )
• LAMP_SIZE ( type: esriFieldTypeSmallInteger, alias: Lamp Size (Watts) , Coded Values: [100: 100] , [150: 150] , [175: 175] , ...10 more... )
• TYPICAL_APPLICATION ( type: esriFieldTypeString, alias: Typical Application, length: 30 , Coded Values: [01: RESIDENTIAL/COMMERCIAL/ROADWAY] , [02: RESIDENTIAL] , [03: COMMERCIAL/ROADWAY] , ...4 more... )
• COMMENTS ( type: esriFieldTypeString, alias: Comments, length: 75 )
• location ( type: esriFieldTypeString, alias: Location on Ground, length: 41 )
• Subdivisio ( type: esriFieldTypeString, alias: Subdivision, length: 50 )
• Thorough_1 ( type: esriFieldTypeString, alias: Street, length: 50 )
• Locations ( type: esriFieldTypeInteger, alias: Location ID )
• Type ( type: esriFieldTypeInteger, alias: Type )
• Contractor ( type: esriFieldTypeString, alias: Contractor, length: 50 )
• Status ( type: esriFieldTypeString, alias: Status, length: 50 , Coded Values: [E: Existing] , [P: Proposed/Future] , [U: Underconstruction] , ...2 more... )
• Qty ( type: esriFieldTypeSmallInteger, alias: Qty )
• GRID ( type: esriFieldTypeString, alias: GRID, length: 2 )
• LIGHTID_1 ( type: esriFieldTypeInteger, alias: LIGHTID_1 )
• SUBGRID ( type: esriFieldTypeString, alias: SUBGRID, length: 5 )
• AS_CODE ( type: esriFieldTypeDouble, alias: AS_CODE )
• InspectedBy ( type: esriFieldTypeString, alias: Inspected By , length: 50 , Coded Values: [City of Allen: City of Allen] , [Contractor: Contractor] )
• InspectionDate ( type: esriFieldTypeDate, alias: Inspection Date, length: 8 )
• KNockdownBy ( type: esriFieldTypeString, alias: Knockdown By, length: 50 , Coded Values: [City of Allen: City of Allen] , [Contractor: Contractor] )
• RepairBy ( type: esriFieldTypeString, alias: Repaired By, length: 50 , Coded Values: [City of Allen: City of Allen] , [Contractor: Contractor] )
• RepairDate ( type: esriFieldTypeDate, alias: Repair Date, length: 8 )
• CWID ( type: esriFieldTypeString, alias: CWID, length: 20 )
• CONTACTS ( type: esriFieldTypeString, alias: CONTACTS, length: 100 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ConvertedYear ( type: esriFieldTypeString, alias: Converted Year, length: 4 )
• PhotoCell ( type: esriFieldTypeString, alias: Photo Cell, length: 4 , Coded Values: [Yes: Yes] , [No: No] )
• UBCell ( type: esriFieldTypeString, alias: UB Cell, length: 4 , Coded Values: [Yes: Yes] , [No: No] )
• TypeofPoleBase ( type: esriFieldTypeString, alias: Type of Pole Base, length: 25 , Coded Values: [Standard Square: Standard Square] , [Standard Tube: Standard Tube] , [Specialty: Specialty] )
• SmallCellNode ( type: esriFieldTypeString, alias: Small Cell Node, length: 4 , Coded Values: [Yes: Yes] , [No: No] )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• METER ( type: esriFieldTypeString, alias: METER OR UNMETER, length: 15 , Coded Values: [Y: Meter] , [N: No Meter] , [UNK: Unknown] )
• SUPP_STRCTRE ( type: esriFieldTypeString, alias: SUPPORT STRUCTURE, length: 20 , Coded Values: [AB: Anchor Base] , [BLK: Black] , [BRZ: Bronze] , ...12 more... )
• OBJECTID_1 ( type: esriFieldTypeInteger, alias: OBJECTID_1 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
