Name: Alleyways

Display Field: AreaName

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Single centerlines that represent the alleys. This feature class also has pavement assessment scores from 2016. </SPAN></P><P><SPAN>It is in a one to many relationship with the AlleySidewalkToAssessmentInspection table. This feature class has a field called ExternalAlleySidewalkKey that relates to ExternalAlleySidewalkSITEKey in the table.</SPAN></P><P><SPAN>This feature class is utilized in Cityworks as a selectable asset.</SPAN></P><P><SPAN>Metadata last edited 5/2021</SPAN></P></DIV></DIV></DIV>

Service Item Id: 3b4ab6d10a604279b061e3877d6f65a1

Copyright Text: City of Allen Tx

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 2509482.592127934
YMin: 7078094.872408718
XMax: 2544170.1339201927
YMax: 7102688.676719636
Spatial Reference: 102738  (2276)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• Category ( type: esriFieldTypeSmallInteger, alias: Category, editable: true, nullable: true, defaultValue: 1, modelName: Category )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• PAssessRating ( type: esriFieldTypeString, alias: Pavement Assessment Rating, editable: true, nullable: true, length: 100, defaultValue: null, modelName: PAssessRating , Coded Values: [A-Excellent: (A) Excellent] , [B-Very Good: (B) Very Good] , [C-Good: (C) Good] , ...3 more... )
• created_user ( type: esriFieldTypeString, alias: created_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: created_user )
• created_date ( type: esriFieldTypeDate, alias: created_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: created_date )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: last_edited_user )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: last_edited_date )
• ExternalAlleySidewalkKey ( type: esriFieldTypeString, alias: ExternalAlleySidewalkKey, editable: true, nullable: true, length: 36, defaultValue: null, modelName: ExternalAlleySidewalkKey )
• AreaName ( type: esriFieldTypeString, alias: AreaName, editable: true, nullable: true, length: 50, defaultValue: null, modelName: AreaName )
• Grid ( type: esriFieldTypeSmallInteger, alias: Grid, editable: true, nullable: true, defaultValue: null, modelName: Grid )
• CWID ( type: esriFieldTypeString, alias: CWID, editable: true, nullable: true, length: 20, defaultValue: null, modelName: CWID )
• Status ( type: esriFieldTypeString, alias: Status, editable: true, nullable: true, length: 20, defaultValue: null, modelName: Status , Coded Values: [E: Existing] , [P: Proposed/Future] , [U: Underconstruction] , ...2 more... )
• InspectedBy ( type: esriFieldTypeString, alias: Inspected By, editable: true, nullable: true, length: 50, defaultValue: null, modelName: InspectedBy )
• InspectedDate ( type: esriFieldTypeDate, alias: Inspected Date, editable: true, nullable: true, length: 8, defaultValue: null, modelName: InspectedDate )
• RepairDate ( type: esriFieldTypeDate, alias: Repair Date, editable: true, nullable: true, length: 8, defaultValue: null, modelName: RepairDate )
• Material ( type: esriFieldTypeString, alias: Material, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Material )
• Comments ( type: esriFieldTypeString, alias: Comments, editable: true, nullable: true, length: 1000, defaultValue: null, modelName: Comments )
• SurfType ( type: esriFieldTypeString, alias: SurfType, editable: true, nullable: true, length: 30, defaultValue: null, modelName: SurfType , Coded Values: [ASPH: Asphalt] , [CONC: Concrete] , [COMBO: Asphalt over Concrete] , ...7 more... )
• Rd_Width ( type: esriFieldTypeDouble, alias: Rd_Width, editable: true, nullable: true, defaultValue: null, modelName: Rd_Width , Coded Values: [12: 12] , [12.5: 12.5] , [13: 13] , ...40 more... )
• Picture ( type: esriFieldTypeString, alias: Picture URL, editable: true, nullable: true, length: 1000, defaultValue: null, modelName: Picture )
• Shape__Length ( type: esriFieldTypeDouble, alias: SHAPE.STLength(), editable: false, nullable: false, defaultValue: null, modelName: SHAPE.STLength() )

Templates:

• Name: Alleyways
  Description:
  Prototype:
  Picture: null
  Rd_Width: null
  Category: 1
  SurfType: null
  PAssessRating: null
  Comments: null
  Material: null
  RepairDate: null
  InspectedDate: null
  ExternalAlleySidewalkKey: null
  AreaName: null
  Grid: null
  CWID: null
  Status: null
  InspectedBy: null

  Drawing Tool: esriFeatureEditToolLine

Relationships:

• AlleyToPavementAssessment (0) -- Related To: AlleySidewalkToAssessmentInspection (2)

Capabilities: Query,Create,Update,Delete,Uploads,Editing

Sync Can Return Changes: true

Is Data Versioned: true

Supports Rollback On Failure: false

Supports ApplyEdits With Global Ids: false

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true
